OEM & ODM services for all kinds of carbon fiber bicycles frame & fork & handlebar

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 1

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 2

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 3

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 4

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 5

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 6

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 7

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L

Place of Origin:

China

Payments:

L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA

Lead Time:

1-5(sets):12(days),6-50(sets):20(days),51-100(sets):30(days),>100(sets):To be negotiated(days)

shipping:

Support Sea freight

Customization:

Customized logo (Min. Order: 100 sets),Customized packaging (Min. Order: 100 sets)

Brand Name:

Pinaworks

Model Number:

CRF36

Inquiry

Write a Review

Bottom Bracket

BB86

Brake

disc-brake

Surface Processing Mode

Matte

Size

XS/S/M/L

Foldable

Weave

Cable guide

internal cable

Warranty

3 Years

Weight

840g±40g(XS SIZE)

Material

Carbon T700

Use

Road Bicycles, ROad bicycles

Type

Carbon Frame, Carbon fiber frame 700C

Keyword

700c Road Bike Frame

Product name

Carbon Road Bike Frame Disc Brake

Place of Origin

Guangdong, China

product description

The CRF36 is a masterpiece in the world of road bikes. It combines outstanding strength and stability with an elegant design. The all-hidden-internal-wiring technology not only enhances the aerodynamic performance but also gives the frame a sleek and modern look. The cylinder yoke and disc brake system provide excellent braking performance and control.

Many professional riders have chosen the CRF36 as their trusty steed, and it has proven its worth time and time again in domestic competitions, bringing home numerous awards. The four available sizes ensure that riders of all heights can find the perfect fit, while the unique lines of the frame offer endless possibilities for customization. Whether It's a simple and elegant design or a bold and vibrant one, the CRF36 can be transformed into a work of art. With its exceptional performance and customizable features, the CRF36 is truly a standout choice for any road cycling enthusiast.

Product Parameters

Size	XS/S/M/L
Model	Road Bicycles frame
Material	T700
headset	Top 1-1/2", Down 1-1/2"
Weight of Frame	840g±40g(XS SIZE)
Fork weight	390g±20g
Seatpost weight	95g±5g
Max imumTyre model	700C * 28mm
DI2&Mechanical	Both support
Seatpost Size	Special seat post
MOQ	1set

Technical Information

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 10

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 11

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 12

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 13

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 14

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 15

The following products are available for you to choose

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 16

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 17

If You Want To See More Carber Fiber Frame Products

Click Here To Contact

Main Product

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 18

Company Profile

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 19

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 20

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 21

Certifications

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 22

Product packaging

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 23

FAQ

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 24

Welcome to visit our website>>szzsbike.en.alibaba.com
Wish You Have A Pleasant Purchasing Time! Pls Click >>Contact Us

CRF36 full carbon fiber road bike frame and fork; carbon fiber handlebar; custom color available XS/S/M/L 25
